Module's documentation

General
1

Hi all,

I would like to use “4 isolated outputs with 6-pin terminal block” together with “4 isolated inputs with 6-pin terminal block“ for connecting to one-wire devices.

Is there a documentation for these modules? Any info about GPIO mapping?

** I need both input and output since I need to read many sensors connected to one-wire bus.

Thanks.

2

For module documentation please refer to their schematics. We published these today.
